Command ASCII (Telnet)
(host to switcher)
Response
(switcher to host)
Additional Description
Decrement horizontal
start value
EX3^-HSRT} HsrtX3^*X3*]
Decrease horizontal start to X3* for X3^.
View horizontal start
value
EX3^HSRT}
X3*]
View horizontal start X3* for X3^.
Verbose response
HsrtX3^*X3*]
Set vertical start value
EX3^*X3(VSRT} VsrtX3^*X3(]
Set vertical start at X3( for X3^.
Increment vertical start
value
EX3^+VSRT} VsrtX3^*X3(]
Increase vertical start to X3( for X3^.
Decrement vertical
start value
EX3^-VSRT} VsrtX3^*X3(]
Decrease vertical start to X3( for X3^.
View vertical start value
EX3^VSRT}
X3(]
View vertical start X3( for X3^.
Verbose response
VsrtX3^*X3*]
Bi-directional serial data port
NOTE: This command sets baud rate only.
Configure parameters
EX11@CP} CcpX11@]
Set rear serial port baud rate
View parameters
ECP} X11@]
Verbose response
CcpX11@]
Firmware version requests
Query firmware version
Q or 1Q
x.xx
]
Gives the number of the currently running
version of the firmware.
Query full firmware
version
*Q
x.xx.xxxx
]
Gives the number and build of the
currently running version of the firmware.
Query verbose version
information
0Q
All responses
from 2Q-3Q-4Q
]
Show bootstrap, factory‑installed, and
updated firmware versions. (See below.)
Example:
1Q Ver01*1.00
Query bootstrap
version
2Q
X12)]
The bootstrap firmware is not user‑
replaceable. This information may be
needed for troubleshooting.
Example:
2Q Ver02*1.00
Query factory firmware
version
3Q
X12)]
Factory‑installed firmware is not user
replaceable.
This firmware is the version the processor
reverts to after a mode 1 reset
Example:
3Q Ver03*1.00
In this example, the factory firmware
version is 1.00 for PVS 405D,.
NOTE: X3^ = PVT SW HDMI RGB D inputs 2 and 4 only
2 = input 2
4 = input 4
X3* = Horizontal start ‑ 0‑255 (128 = default)
X3( = Vertical start ‑ 0‑255 (128 = default)
X11@ = Baud Rate:
0 = 9600 (Default)
1 = 19200
2 = 38400
3 = 115200
X12) = Firmware Query (‘Q’ commands)
*Q = Firmware and build number [<X.YY.ZZZZ> ]
0Q = Verbose version information [<2Q> ‑ <3Q> ‑ < 4Q>] sum of responses from 2Q‑3Q‑4Q.
1Q = Firmware version [<currently running code (X.YY)>]
2Q = Final stage bootloader (Uboot) version [<X.YY>]
3Q = Factory base code version [<factory base code (X.YY)>*]
4Q = Updated firmware version [<updated code version (X.YY)>*]
PVS 405D • SIS Communication and Control 28
