En-35
RGB/PC1
RGB/PC1
RGB/PC1
RGB/PC1
RGB/PC1
RGB/PC1
Side-by-Side Picture-in-Picture
SELECT/
FREEZE
button
SELECT/
FREEZE
button
S BY S1
RGB/PC1
RGB/PC1
or
S BY S2
Switching the input source quickly
This feature enables quick input selection.
After setting ON, press the CLEAR/SEAMLESS SW
button for quick switching between the two selected input
signals.
Example: Set to switch quickly between RGB1 and
RGB2.
On “SEAMLESS SW” of “OPTION4” menu, select “ON”.
Select “RGB1” and “RGB2”.
SEL. ADJ. RETURN
OPTION4 4 / 4
PREVIOUS PAGE
SUB. PICTURE
ZOOM NAV
PIC FREEZE
SEAMLESS SW
SELECT1
SELECT2
TEXT INSERT
: BTM LFT
: S BY S1
: ON
: RGB1
: RGB2
: OFF
EXIT
* The available sources depend on the settings of input.
Information
Ⅵ SEAMLESS SW Function
* This feature will not function for certain input
combinations. See the table on page En-15.
* After switching to the selected input, please operate this
function.
* This feature will not function during split screen mode.
* When SEAMLESS SW is first turned on, or when
signals being transmitted are changed, there may be a
slight delay due to signal analysis.
Ⅵ SEAMLESS SW settings
OFF: Turns off the SEAMLESS SW function.
ON: When the CLEAR/SEAMLESS SW button is
pressed, input signals will switch quickly according to
the setting of SELECT1 and SELECT2.
Displaying the information as a text
Example: Setting “TEXT INSERT” to “BOTTOM”,
“INPUT” to “RGB1”, “PIC. RATE” to “100%” and
“DISPLAY” to “NORMAL”
On “TEXT INSERT” of “OPTION4” menu, select
“BOTTOM”, then press the MENU/ENTER button.
The “TEXT INSERT” screen appears.
Adjust the items.
SEL. ADJ. RETURN
TEXT INSERT
INPUT
PIC. RATE
DISPLAY
: RGB1
: 100%
: NORMAL
EXIT
Information
Ⅵ TEXT INSERT setting
OFF: Displays no text.
TOP/MID HIGH/MID LOW/BOTTOM: Displays a
text at the specified location.
Ⅵ INPUT setting
Sets the input of the text to the RGB1 to 3.
Ⅵ PIC. RATE setting
Sets the transparency of the text.
Ⅵ DISPLAY setting
NORMAL: The sub screen is displayed consistently.
FADE: The sub screen fades in.
Enhanced split screen Model
