stomizing the Function Settings (continued)
(Continued)
When you select "Analog 6Oh':
Make the following settings for the built-in 5.1ch
surround decoder.
ยข (Center)Speaker On
$ (Surround)Speaker On
Subwoofer On
Center ChannelDelay Omse(
SurroundChannelDelay 5msec
TestTone
1) Select an item b moving the cursor control
(A / T), and press the ENTER button.
2) Make the settings (see below) by moving the
cursor control, and press the ENTER button.
C.S.Speaker Size
Small: When the center speaker or surround
speakers cannot reproduce low frequency
signals below 120 Hz.
Large: When the center speaker and surround
speakers can reproduce low frequency
signals below 120 Hz.
C(Center) Speaker
Off: When center speaker is not connected.
On: When you connect center speaker.
S(Surround) Speaker
Off: When surround speakers are not connected.
On: When you connect surround speakers.
Subwoofer
Off: When a sub woofer is not connected.
On: When you connect a sub woofer.
Note
Depending on the sound in a DVD audio disc,
speakers may output each sound of recorded
channels, regardless of your settings.
Adjusting the delay time:
When enjoying 5.1ch surround playback, itis ideal
to choose a listening position that is the same
distance from each speaker. By adjusting the
delay time of the center/surround speakers, you
can virtually create an ideal listening environment
(as if the center/surround speakers were at their
ideal locations respectively as below.)
......./-- Ideal location of a
..._enter speaker
(A) d
_ E (nAt)//_ All speakers shoul
( [] _ _Df / be/_eCatitd _irtahdnua
\ ,- s_/ofDf
's ea'o'OC tsg:Ofa
Center Channel Delay
0msec: When Df equals Dc.
1msec: When (A) isapprox. 34 cm (13 inch)
2msec: When (A) isapprox. 68 cm (27 inch)
3msec: When (A) isapprox. 102 cm (40 inch)...
*(A) = Df- Dc
Get your optimum value (0, 1,2... 5)
dividing (A) by 34.
Surround Channel Delay
0msec: When Df equals Ds.
lmsec: When (B) is approx. 34 cm (13 inch)
2msec: When (B) is approx. 68 cm (27 inch)
3msec: When (B) is approx. 102 cm (40 inch)...
*(B) = Df- Ds
Get your optimum value (0, 1,2... 15)
dividing (B) by 34.
Note
Depending on the sound ina DVD audio disc, the
DVD player may adjust delay time as "Omsec,"
regardless of your delay time settings.
