Section 2
Receiving & Installation
Receiving & Installation 2-1
Receiving
The control is thoroughly tested at the factory and carefully packaged for
shipment. When you receive your control, there are several things you
should do immediately.
1. Observe the condition of the shipping container and report any
damage immediately to the commercial carrier that delivered your
control.
2. Verify that the part number of the control you received is the same
as the part number listed on your purchase order.
3. If the control is to be stored for several weeks before use, be sure
that it is stored in a location that conforms to published storage
specifications.
Physical Location
The location of the control is important. It should be installed in an area
that is protected from direct sunlight, corrosives, harmful gases or
liquids, dust, metallic particles, and vibration. Exposure to these
elements can reduce the operating life and degrade performance of the
control.
Installation
Control Installation
Refer to the mounting dimensions and hole locations shown in Figure
2-1. Mount the control to the mounting surface using appropriate
hardware (not provided).
