SAVE THESE INSTRUCTIONS
Page 18
(131) MODEL CS8110 SALTWATER SYSTEM ENGLISH 7.5” X 10.3” PANTONE 295U 07/28/2010
English
OPERATION INSTRUCTIONS
OOPPEERRAATTIINNGG IINNSSTTRRUUCCTTIIOONNSS
1. Turn on the filter pump.
2. Start up the unit:
Plug the power cord into the electrical
outlet and test the GFCI/RCD (circuit breaker).
S
witch on the unit. Code “00” appears on
the electronic control station’s LED, indicating
that the unit is in a Stand-By Mode. This is normal.
3. Unlock keypad controls:
Press and hold the -- button for 2 seconds until you hear a
short “beep”. Then press and hold the button for another 2
seconds until you hear the second short “beep”. The LED
flashes “00”. This procedure unlocks the keypad control
buttons.
4. Set operating hours for Saltwater system:
Increase the scheduled number of operating
hours by pressing the button . Or reduce
them by pressing the button . See the
“Operating Time Table” for the required
operating hours related to each pool size.
Press the button to select the desired
hours. You can press if you have
selected too many hours. The built-in timer
will now activate your Saltwater System, at
the same time each day, for the number of
hours you have set.
NOTE: The Saltwater System will not operate if the filter pump is not operating.
Make sure to program your filter pump (or start it manually) for operation
beginning 5 minutes before the saltwater system and finishing 15 minutes after
the saltwater system.
5. Lock keypad controls:
With the desired hour value showing, press and hold the
button for 2 seconds until you hear a long “beep”. Then press
and hold for another 2 seconds until you hear the second
long beep. A green “WORKING” indicator on the control panel
will light up within a few seconds to indicate that the saltwater
system has started chlorine production. Locking the control
buttons into this setting prevents unauthorized changing of the
operating cycle.
NOTE: If you forget to lock the keypad controls, the system will
automatically lock it and start working 1 minute later.
6. Readjust operating time if necessary:
The operating hours can be re-adjusted if necessary. Just repeat the steps 3
through 5.
7. Test the copper concentration in the
pool water.
The Saltwater System recommends a
copper level of 0.1 to 0.2 ppm. This is
easily tested by the copper ion test strips
provided. If the test result is 0.1~0.2ppm,
go directly to step 9.
(1 to 12 hours max per cycle)
OK
0
Copper (ppm)
0.1 0.2 0.5 0.9 1.3
