SAVE THESE INSTRUCTIONS
Page 26
(131) MODEL CS8110 SALTWATER SYSTEM ENGLISH 7.5” X 10.3” PANTONE 295U 07/28/2010
English
TROUBLESHOOTING GUIDE (continued)
1. Filter pump not attached to
system and/or switch on.
2. Circulation line is blocked.
3. Incorrect inlet and outlet hose
direction.
4. Incorrectly installed flow sensor
conduit.
5. Scale on the flow sensor.
6. Flow sensor cord is loose.
7. Flow sensor failure.
8. Inner timer conflict between
filter pump and saltwater system.
1. Dirt or scale on titanium plates.
2. Low salt level / No salt.
3. Electrolytic cell cord is loose.
4. Possible electrolytic cell failure.
1. High salt level.
1. Display and all lights are off - the
system does not power up.
• Ensure filter pump is attached and
operating. See "Setup Instruction".
• If your unit has plunger valves, ensure
that they are open.
• Clear your filter cartridge and cell from
debris and dirt. See “Maintenance”.
• Release all trapped air in the circulation
line. See the filter pump manual.
• Check the direction of the inlet and the
outlet hose. Reverse the hoses if
necessary. See “Set Up Instructions”.
• Check that the arrow on the flow sensor
conduit points in the same direction as
the one on the cell. Reverse the flow
sensor conduit if necessary.
• Clean the flow sensor, paying special
attention to the hinge. See
“Maintenance”.
• Plug the flow sensor firmly into the flow
sensor receptacle.
• Contact Intex Service Center.
• Reset both timers on the filter pump and
saltwater system.See “Boost Cycle”.
• Remove the electrolytic cell for
inspection. Clean it if necessary.
See “Maintenance”.
• Add salt. See “Salt & Pool Water
Volumes”.
• Ensure that the cell cord is plugged
firmly into the cell housing receptacle.
• Contact Intex Service Center. Replace
the cell if needed.
• Partially drain the pool and refill it with
fresh water. See “Salt & Pool Water
Volumes”.
• Household voltage is too high or too low
(+
20%). Check the voltage is within the
range stated on the device housing.
• Contact Intex Service Center.
LED PANEL
CODE
P
ROBLEM
SOLUTION
LED Panel Code Flash & Alarm On (NOTE: Always turn off the power before cleaning and servicing).
TTRROOUUBBLLEESSHHOOOOTTIINNGG GGUUIIDDEE
