SAVE THESE INSTRUCTIONS
Page 7
(131) MODEL CS8110 SALTWATER SYSTEM ENGLISH 7.5” X 10.3” PANTONE 295U 07/28/2010
English
PPRROODDUUCCTT IINNFFOORRMMAATTIIOONN//SSPPEECCSS
This product is specially designed for above ground pools. It will destroy the
bacteria, oxidize bather organics and control algae, which provide a safe, clean and
comfortable swimming pool.
C
ommon salt (sodium chloride) is made up of two elements, sodium and chloride.
During the installation of your Saltwater System, a measured quantity of salt is
dissolved in the pool water to make it slightly salty. The pool water flows through
the Saltwater System ’s electrolytic cell to produce chlorine. The chlorine dissolves
in the water and instantly starts destroying bacteria and algae. It also oxidizes all
other organic materials.
Low voltage direct current is applied to the copper electrode, and copper ions are
generated and dissolved instantly in the water. Copper is an effective algaecide,
which will prevent algae from growing in the pool.
HOW THE CHLORINE IS GENERATED
Power: 110 - 120 Volt AC
Amperage: 1.1A
Wattage: 125W
Ideal Salt Level: 3000 ppm (parts per million)
Maximum Chlorine Output/hour: 12 grams/hour
Copper Ionizer Output Current: 175 mA
Minimum Flow Rate:
700 ~ 4000 gallons/hour (2650 - 15140 liters/hour)
Limited Warranty: 2 Years (see “Limited Warranty”)
HOW COPPER IONS ARE GENERATED
PRODUCT SPECIFICATIONS
Copper electrodes
Hose from
Filter Pump
Flow Sensor
Electronic
Control Station
Power Supply
Electrolytic Cell
Power Switch
Hose Returning
Water to Pool
