4-21
IPL 250 • SIS Programming and Control
Command/response table for SIS commands (continued)
Command ASCII (Telnet)
(host to IPL)
URL Encoded (Web)
(host to IPL)
Response
(IPL to host)
Additional description
Read/view e-mail events
E
X4%
CR
}
W
X4%
CR
| X4^
,
X4&
]
Send e-mail file specified in the
e-mail event configuration
24
E X4%
SM
}
W
X4%
SM
|
Eml
X4%
] X4%
= e-mail event number (1 - 64).
Send a different e-mail file (one not configured in an e-mail event)
24
X7%
is an optional string for a destination
e-mail address in the form of test@extron.
com.
X7)
= The number to insert into an e-mail
messageifa____.eml file has an embedded
server-sideinclude“<!--#echovar=
“WCR
|
” -->” (the
E}
command with
no parameters.) The numeral is a 16-bit
number to be employed as the user defines.
This is an optional parameter. Use 0 as a
placeholder if the optional
X4&
variable is
used but
X7)
is not needed.
X4&
= xxx, where xxx = a number 1 to 999
corresponding to the e-mail’s filename (xxx.
eml). If xxx = 0 or no parameter is given, the
unit sends the file that was set via the CR
command.
E X7%
,
X4%
,
X7)
,
X4&
SM
}
W
X7%
%2C
X4%
%2C
X7)
%2C
X4&
SM
|
Eml
X4%
]
N
If file
X4&
.eml is not found when the SM command is executed, the IPL sends a default e-mail message.
Set e-mail server IP address and user domain name
24
X1$
= IP address (xxx.xxx.xxx.xxx). Leading
zeros are optional in setting values. Leading
zeros are suppressed in returned values.
X1%
= E-mail domain name, e.g., extron.com
X7#
= An e-mail account username (for
SMTP authentication) of up to 31 characters.
Do not use commas. This parameter is
optional during setup.
X7$
= An e-mail account password (for
SMTP authentication) of up to 31 characters.
Do not use commas. This parameter is op-
tional during setup. In a response, instead
of the actual password,
X7$
is displayed as 4
asterisks (****) if a password has been set up
or as nothing ( ) if it has not.
E
X1$
,
X1%
,
X7#
,
X7$
CM
}
W
X1$
%2C
X1%
%2C
X7#
%2C
X7$
CM
|
Ipm•
X1$
,
X1%
,
X7#
,
X7$
]
Read/view e-mail server IP address and user domain name
E
CM
}
W CM
| X1$
,
X1%
X7#
,
X7$]
