5HIHUHQFH0DQXDO
00809-0100-4811, Rev AA
October 2002
A-9
Rosemount 3300 Series
Example model string: 3301-H-A-1-S-1-V-1A-M-02-05-AA-I1-M1C1.
E-02-05 in model string denotes 2ft 5 inch probe length.
M-02-05 in model string denotes 2.05 m probe length.
AA
AB
BA
BB
CA
CB
DA
2 inch ANSI, 150 lb
2 inch ANSI, 300 lb
3 inch ANSI, 150 lb
3 inch ANSI, 300 lb
4 inch ANSI, 150 lb
4 inch ANSI, 300 lb
6 inch ANSI, 150 lb
HB
IA
IB
JA
JB
KA
DN50, PN40
DN80, PN16
DN80, PN40
DN100, PN16
DN100, PN40
DN150, PN16
RA
RB
SA
SB
1.5 inch NPT thread
1 inch NPT thread
1½ inch BSP (G 1½ inch) thread
1 inch BSP (G 1 inch) thread
NA
E1
E5
E6
I1
I5
I6
No hazardous Locations Certifications
ATEX Flameproof
FM Explosion proof
CSA Explosion proof
ATEX Intrinsic Safety
FM Intrinsic Safety and Non-Incendive
CSA Intrinsic Safety and Non-Incendive
M1
BT
P1
N2
Integral Digital Display
Bar Code Tag with tag number and purchase order number
Hydrostatic testing
NACE material recommendation per MR 01-75
(1)
C1
C4
C5
C8
Factory configuration (CDS required with order)
Namur alarm and saturation levels, high alarm
Namur alarm and saturation levels, low alarm
Low alarm
(2)
(standard Rosemount alarm and saturation levels)
Q4
Q8
Calibration Data Certification
Material Traceability Certification per EN 10204 3.1B
(3)
