Rosemount 3300 Series
4-8
Figure 4-6. HART Communicator Menu Tree
2PV
3AO
4LRV
5URV
2Level
3 Distance
4 Volume
5 Internal Temp
6 Interface Dist
7 Interface Level
8 Amplitude Peak 1
- Amplitude Peak 2
- Amplitude Peak 3
- Upper Prod Thickn
2 Loop Test
3D/A Trim
1Tag
4Ref Height
5 Probe Length
6Probe Type
7 Vapor Dielectric
8 Product Dielectric
9Measurement
Mode
- Upper Null Zone
- Probe Angle
- Max Up Prod Tkn
1Level Units
2 Volume Units
3 Temperature Units
1Distributor
2 Model
3 Dev Id
4Tag
5Date
6Write Protect
7 Descriptor
8 Message
2 Tank Diameter
3 Tank Height
1PV LRV
2 PV URV
3 PV % range
4Damp
5 Upper Null Zone
6 Alarm/Sat Levels
1Gain Control
2 Thresholds
3 Reset to Default
4 Calibration Offst
1Flange Type
2 Flange Material
3Meter
4 Probe
5 Probe Type
1Entries Used
2Max Entries
3 Lvl0
4Vol0
5 Lvl1
6Vol1
7 Lvl2
8Vol2
9 Lvl3
Vol3
Lvl9
Vol9
1AO
2 AO Alarm Type
4 D/A Trim
5 Scaled D/A Trim
1Poll addr
2 Num req preamps
3Burst mode
4 Burst option
1Strap Table
2 Ver Cylinder
3 Hor Cylinder
4 Vert Bullet
5 Hor Bullet
6 Sphere
7None
1Variable re-map
2 PV is
3 SV is
4TV is
5QV is
- Level
- Distance
- Volume
- Internal Temp
- Interface Dist
- Interface Level
- Amplitude Peak 1
- Amplitude Peak 2
- Amplitude Peak 3
- Upper Prod Thickn
2 Master Reset
1Status Group 1
2 Status Group 2
1Universal rev
2 Fld dev rev
3 Software rev
1Display variables
2 Display language
1High Alarm
2 Low Alarm
3 High Saturation
4 Low Saturation
5 AO Alarm Type
1Apply values
2 Range values
3 PV % rnge
