30
Press and hold the POWER/LIGHT key for 3 seconds to turn the unit off. A message will appear
telling you how many seconds there are until shutdown occurs. Your 700 Series™ Fishing System
should always be turned off using the POWER/LIGHT key. This will ensure that shutdown occurs
properly and any menu settings will be saved.
VIEW Key
The VIEW key is used to cycle through all available views. Press the VIEW key to
advance to the next view. Repeatedly pressing VIEW cycles through all views
available. Views can be hidden to optimize the system to your fishing
requirements (see Views Menu Tab).
INFO Key
Info - Press the INFO key while in Bird's Eye, Chart or Combo View to display
information about objects that are nearest to an active cursor.
If the cursor is not active, the following menu will be displayed. Use the 4-
WAY Cursor key to select Nearest Port, Nearest Tide Station or Nearest
Current Station, then use the RIGHT Cursor key to display the requested
information.
NOTE: The built-in UniMap™ does not contain Port, Tide or Current
information. This information is only available from optional purchase
MMC/SD cards.
MENU Key
The MENU key is used to access the menu system.
Start-Up Options Menu - Press the MENU key during the power up sequence to view the Start-Up
Options menu.
X-Press
TM
Menu - Press the MENU key once for the X-Press
TM
Menu. The X-Press
TM
menu allows you
to access frequently-used settings without having to navigate through the whole menu system.
When the X-Press
TM
menu is displayed, you can use the UP or DOWN Cursor keys to move to a
particular menu choice. As soon as you alter a parameter (using the RIGHT or LEFT Cursor keys) the
X-Press
TM
menu will collapse temporarily, and the screen will update if it is affected by your menu
setting change, allowing you to see the effects of your action immediately. Reactivate the X-
Press
TM
Menu by using the UP or DOWN Cursor keys.
