51
Remove Target
(only if a Target is Active)
Remove Target removes the waypoint target from the display. This menu choice will only appear
when a target has already been applied to a waypoint.
NOTE: See Add a Waypoint Target or Trolling Grid for more information.
To Remove a Target:
1. Highlight Remove Target on the Navigation X-Press
TM
menu.
2. Use the RIGHT 4-WAY Cursor Control key to remove the target.
Remove Grid
(only if a Grid is Active)
Remove Grid removes the waypoint grid from the display. This menu choice will only appear
when a grid has already been applied to a waypoint.
NOTE: See Add a Waypoint Target or Trolling Grid for more information.
To Remove a Grid:
1. Highlight Remove Grid on the Navigation X-Press
TM
menu.
2. Use the RIGHT 4-WAY Cursor Control key to remove the grid.
Sonar Window
(Combo view only)
Sonar Window sets the size of the Sonar Window in the Combo View. Sonar Window can only be
accessed from the Combo View.
To Set the Size of the Sonar Window in the Combo View:
1. Highlight Sonar Window on the Navigation X-Press
TM
menu.
2. Use the LEFT or RIGHT 4-WAY Cursor Control keys to adjust the size of the sonar window.
(Wide, Medium, Narrow, Default = Medium)
