GPS chartplotters Page 75
14. SPECIFICATIONS
14.0a CP155C SPECIFICATIONS
Power consumption : 600mA max @12V
Power supply : 12 Volt DC, 7 Watt max
Interface : Input/Output Interface NMEA-0183
Display : TFT Color LCD
(active area 5,7") sunviewable tecnology
Display Resolution : 320 x 240 pixels
Cartography : C-MAP NT
+
C-CARD
Operating temperature range : 0/+55 degrees Celsius
Storage temperature : -20/+70 degrees Celsius
Water Resistence : splash-proof
Memory : Non volatile with battery backup
Keyboard : Silicon rubber, backlight
Weight : 900 gr. (2 pounds)
User Points (Marks/Waypoints): 600
Routes : 20 (max 30 Waypoints each)
Track Points : 3000 (recordable in 5 Tracks)
Figure 14.0a - CP155C chartplotter Dimensions [mm/inch]
