14.1 SMART WAAS RECEIVER SPECIFICATIONS
This Smart DGPS WAAS receiver is based on a ultimate 12 channel GPS engine that
delivers accuracy better than three meters by decoding the GPS correction signals from the
satellite-based WAAS (Wide Area Augmentation System). The GPS engine, interface
electronics and the passive antenna are enclosed inside the water-proof plastic housing.
This provides advanced state of the art GPS performance in an easy to use package.
PHYSICAL CHARACTERISTICS
Color : Ivory white.
Dimensions : 97mm in diameter x 32mm in height (flush mounted) or 61,5mm
on flag-pole mount.
Weight : 160 grams (without cable).
Cable GPH 10 : white 15 meter 8x28AWG cable with 6 pins female connector
ELECTRICAL CHARACTERISTICS
Input Voltage : 10 Vdc to 35 Vdc unregulated.
Input Corrent : 112 mA @ 12 Vdc
60 mA @ 24 Vdc
45 mA @ 35 Vdc
GPS Receiver Sensivity : -145 dBW minimum
GPS PERFORMANCE
Receiver : WAAS (North America), EGNOS (Europe), MSAS (Asia)
Geodetic Datum : WGS84
Channels :12
Frequency : 1575.42MHz (L1, C/A code)
ACQUISITION TIME (Approximate)
Reacquisition : less than 1 second
Hot Start : 8 seconds (typical)
Warm Start : < 40 seconds (typical)
Cold Start : < 45 seconds (typical)
ACCURACY
Position : less than 10' (3m), 95% of the time
Speed : 0.3 Knots RMS
NMEA OUTPUT MESSAGES/UPDATE RATE
GGA : 1 second
GLL : 1 second
VTG : 1 second
RMC : 1 second
GSA : 3 seconds
GSV : 3 seconds
PCMPD : 1 second
