Programmer’s Guide, cont’d
MTPX Plus Twisted Pair Matrix Switchers • Programmer’s Guide
4-10
Command ASCII command
(host to switcher)
Response
(switcher to host)
Additional
description
Create ties
N
•Commandscanbeenteredback-to-backinastring,withnospaces.Forexample:1*1!02*02&003*003%4*8$.
•
The quick multiple tie and tie input to all outputcommandsactivateallI/Oswitchessimultaneously.
•
Thematrixswitcherssupport1-,2-,and3-digitnumericentries(1*1,02*02,or001*001).
N
The& tiecommandforRGBandthe%tie command for video can be used interchangeably on the matrix switchers.
Tie input
X! to output X@,
video (V) and audio (A)
X!
*
X@
! Out
X@•
In
X!•
All
]
Tie input
X!
‘s video and
audio to output
X@
.
Example:
1*3!
Out03
•
In01
•
All
]
Tie input 1 video and audio
to output 3.
Tie input
X! to output X@,
RGB (video) only
X!
*
X@
& Out
X@•
In
X!•
RGB
]
Audio breakaway.
Example
(see2ndNote,above):
10*4&
Out04
•
In10
•
RGB
]
Tie input 10 RGB to output 4.
Tie input
X! to output X@,
video only
X!
*
X@
% Out
X@•
In
X!•
Vid
]
Audio breakaway.
Example
(see2ndNote,above):
7*5%
Out05
•
In07
•
Vid
]
Tie input 7 video to output 5.
Tie input
X! to output X@,
audio only
X!
*
X@
$ Out
X@•
In
X!•
Aud
]
Audio breakaway.
Example:
12*4$
Out04
•
In12
•
Aud
]
Tie input 12 audio to output 4.
Quick multiple tie
E
+Q
X!
*
X@
!...
X!
*
X@
$
}
Qik
]
Example:
E
+Q3*4!3*5%3*6$
}
Qik
]
Tie input 3 video and audio
to output 4, tie input 3 video
to output 5, and tie input 3
audiotooutput6.
Tie input to all outputs,
video and audio
X!
*! In
X!•
All
]
Example:
5*!
In05
•
All
]
Tie input 5 video and audio
to all outputs.
Tie input to all outputs,
RGB (video) only
X!
*& In
X!•
RGB
]
Audio breakaway.
Example
(see2ndNote,above):
8*&
In08
•
RGB
]
Tieinput8RGBtoall
outputs.
Tie input to all outputs,
video only
X!
*% In
X!•
Vid
]
Audio breakaway.
Example
(see2ndNote,above):
10*%
In10
•
Vid
]
Tie input 10 video to all
outputs.
Tie input to all outputs,
audio only
X!
*$ In
X!•
Aud
]
Audio breakaway.
Read ties
N
The&read tiecommandforRGBandthe%read tie command for video can be used interchangeably on the matrix
switchers.
Read RGB
(video) output
tie
X@
&
X!]
RGB input
X!
is tied to
output
X@
.
Read video
output tie
X@
%
X!]
Video input
X!
is tied to
output
X@
.
Read audio
output tie
X@
$
X!]
Audio input
X!
is tied to
output
X@
.
Command/response table for SIS commands
N
X!
= Input number
00 – (maximum number of inputs for your model) (00 = untied)
X@
= Output number 01 – (maximum number of outputs for your model)
