Updating firmware
The firmware upgrade utility provides a way to replace the firmware that is coded
on the switcher’s control board without taking the switcher out of service.
Update the switcher firmware as follows:
1. Visit the Extron Web site, www.extron.com, click the Download Center tab,
and then click the Firmware link (figure 5-9).
3
2
3
1
1
This sequence is shown for
example only.
For the MTPX Plus,
the firmware file selected and
shown is “MTPX Plus”.
NOTE
Figure 5-9 — Location of firmware upgrade files
2. Selecttheappropriatermwarele(MTPX1616Series)todownloadandclick
Download.
3. Enter the requested personal information and then click Download to copy the
firmware to your computer.
4. Click Run twice (figure 5-10 on the next page). The PC downloads the
firmware update from the Extron Web site and starts the Extron Installation
Program to extract the firmware file.
5. Click Next. The program extracts the firmware files and places them in a
folder identified in the InstallShield Wizard window.
N
Note the folder to which the firmware file is saved.
6. Click Finish to exit the program.
