102
SI Range
Settings: Auto, 6 to 360 feet, or 2 to 120 meters
[International Models only]; Default = 150 feet, 50 meters
SI Range sets the deepest range that will be displayed on the Side Imaging®
Views. The range must be set manually.
Chart Speed
Settings: 1-9, Ultra, where 1 = Slow, 9 = Fast, Ultra =
Fastest; Default = 5
Chart Speed determines the speed at which the side sonar information moves
down the display, and consequently the amount of detail shown. A faster
speed shows more information in the Side Imaging® Views and is preferred by
most anglers; however, the sonar information moves across the display quickly.
A slower speed keeps the information on the display longer, which allows you
to see an entire area.
Imaging Colors
Settings: Blue, Amber 1, Amber 2, Brown, Green, Inverse,
Gray, Green/Red; Default = Blue
Imaging Colors allows you to select which color palette you would like to use
for the Side Imaging® display. Imaging Colors also changes the palette used in
the Down Imaging® View.
Choose a low range number to focus on a shorter distance of the water
column and see greater detail on the screen. Choose a higher range number
to view farther into the water and see an overview of details on the screen.
Side Imaging® X-Press™ Menu
