44
Split Sonar View
Split Sonar View displays sonar returns from each down beam frequency on
separate sides of the screen. You can use the Split Sonar View to make side by
side comparisons between the sonar returns from both beams.
• Sonar returns from the 83 kHz wide beam are displayed on the left side
of the screen and sonar returns from the 200 kHz narrow beam are
displayed on the right side of the screen.
• Depth is displayed in the upper left hand corner.
• The Digital Readouts in the Split Sonar View cannot be customized;
therefore, information such as water temperature and voltage are
unavailable in the Split Sonar View.
200/83 kHz Split Sonar View
Depth
83 kHz Sonar
History Window
200 kHz Sonar
History Window
Upper Depth
Range
Lower Depth
Range
Views
