163
NMEA 0183 Output
(Advanced)
Settings: Off, On; Default = Off
NMEA 0183 Output turns the NMEA* output on or off. NMEA Output should
be turned On if you connect the NMEA Output wires of the GPS Receiver cable
to another NMEA-compatible device, such as an autopilot.
*NMEA 0183 is a National Marine Electronics Association standard for data
communication.
NOTE: A separate purchase of accessory AS-HHGPS may be required for the
NMEA output function.
The following NMEA sentences are output when NMEA 0183 Output is
turned On:
DPT - Depth
MTW - Water Temperature
GLL - Lat/Lon Position
GGA - GPS Fix Data
RMC - Recommended Minimum Specific GNSS Data
VTG - Course Over Ground and Ground Speed
ZDA - Time and Date
When navigating, the following NMEA sentences are also output when
NMEA 0183 Output is turned On:
APB - Autopilot Sentence B
BWR - Bearing and Distance to Waypoint
RMB - Recommended Minimum Navigation Info
Sonar
Settings: Off, On; Default = Off
Sonar sets whether the Sonar views are shown in the View rotation. Select Off
to deactivate Sonar and remove the Sonar Views from the View rotation.
Setup Menu Tab
