21
What’s on the Sonar Display
the area under your boat, including the following items:
either device is connected to the 300 Series™ Fishfinder.If both devices are connected,
RTS (Real Time Sonar) Window™
Structure - Where fish may be hiding.
Thermoclines - Layers of water with different
temperatures that appear at different depths
and different times of the year. A thermocline
typically appears as a continuous band of
many colors moving across the display at the
same depth.
Cursor - Available in Freeze Frame and can
be positioned in the Sonar View to provide
depthofa sonarreturnandbottomdepthbelow
the cursor.
Low Sonar Intensity Return
High Sonar Intensity Return
Bait Ball
Fish - The Fishfinder displays fish as arches
and/or fish icons, and can be set to alarm
when a fish of a certain size is detected.
When a target is detected, a Fish ID+™
symbol appears on the display with the
depth displayed above it. The size of the
symbol indicates the intensity of the sonar
return. The unit will clearly show schools of
Bait Fish as "clouds" of different shapes and
sizes, depending on the number of fish and
boat speed.
