Accessory Bus
Use the Accessory Bus to expand the
functionality of your 900 Series™. Accessories
plug directly into the 900 Series™, enabling
Advanced features such as WeatherSense®
and the SmartCast® Wireless Sonar Link.
Additional tabs and menu choices will be
added to the menu system automatically when
an accessory is plugged into the unit. In
addition, multiple accessories can be attached
simultaneously. See Accessories Menu Tab
and 900 Series™ Accessories in this manual,
as well as your accessory Operations Manual
for additional details.
NOTE: Accessories to enable WeatherSense® and the SmartCast® Wireless Sonar Link
require separate purchases. You can visit our website at www.humminbird.com or
contact our Customer Resource Center at 1-800-633-1468 for additional details.
Installation Overview
Please read all instructions that are relevant for your configuration before
beginning the installation process.
NOTE: Installation procedures will depend on product configuration.
The 900 Series™ has a wide variety of configurations.
Sonar Transducer w/Temperature
1
Optional “Y”Cable
2
Power
3
Speed through water
GPS Receiver
WeatherSense®
5
6
7
Temperature/Speed
4
SmartCast® Wireless Sonar Link
8
5
Accessory Bus
1
2
3
4
5
6
7
8
Accessory Bus
