Fish ID Sensitivity
Fish ID Sensitivity adjusts the threshold of
the Fish ID+™ detection algorithms. Selecting a higher setting allows
weaker returns to be displayed as fish. This is useful for identifying smaller
fish species or baitfish. Selecting a lower setting displays fewer fish from
weak sonar returns. This is helpful when seeking larger species of fish. Fish
Sensitivity is used in conjunction with Fish ID+™. Fish ID+™ must be On for
Fish Sensitivity to affect the ability of the 900 Series™ to identify sonar
returns as fish.
T
o change the Fish ID Sensitivity setting:
1. Highlight Fish ID Sensitivity on the Sonar main menu.
2. Use the LEFT or RIGHT 4-WAY Cursor Control keys to change the Fish
Sensitivity setting. (Low = 1, High = 10, Default = 5)
Real Time Sonar (RTS®) Window
RTS® Window sets the RTS® Window to
either Wide or Narrow, or turns it off in the Sonar View. The RTS® Window
always updates at the fastest rate possible and only displays returns that are
within the transducer beam. (See Getting Started - Using Your 900
Series™: Real Time Sonar [RTS®] Window for more information.)
T
o change the RTS® Window setting:
1. Highlight RTS® Window on the Sonar
main menu.
2. Use the LEFT or RIGHT 4-WAY Cursor
Control keys to change the RTS® Window
setting. (Wide, Narrow, Off, Default =
Narrow)
RTS® Window (Wide)
RTS® Window (Narrow)
RTS® Window (Off)
88
