NorthStar Navigation EXPLORER 657 Fish Finder User Manual



61Northstar Explorer 657 Installation and Operation Manual
Press twice, then select System:
Language
Select the language for the displays.
Tip:
In case you can’t read the current
language, the language setting is found at the top
of the system menu.
Backlight
Select the backlight level for the keys and display
(see also section 2-3)
Night mode
Night mode sets the palette for all displays.
Normal palette, for daytime
All displays have a palette optimised for night
time.
See also section 2-3. To change only the chart
palette, see section 17-2.
Key beep
Enables or disables the beep when a key is pressed.
Auto power off
See section 2-2.
Factory reset
This option returns all of the 657 settings (except
the language, waypoints and routes) to the default
factory settings shown on the setup menus.
About window
The about window shows:
The software version and date.
The world chart version.
Any card fitted.
17-1 Setup > System
The number of waypoints, routes and tracks
you have stored.
Connector wiring information.
In the unlikely event of having to contact a
Northstar dealer for service, quote the software
version number and date.
Sonar
Disable any sonar transducer and disable sonar
functions.
A sonar transducer is fitted. Enable sonar
operation.
See section 18-6.
SmartCraft™
No SmartCraft™ gateway is fitted. Disable
SmartCraft™ functions.
SmartCraft™ gateway is fitted. Enable
SmartCraft™ operation.
See section 18-8.
AIS
No appropriate AIS receiver is fitted. Disable
AIS.
An appropriate AIS receiver is fitted.
Enable AIS.
See section 17-11.
Buddy track
No DSC VHF radio is fitted. Disable Buddy track.
A DSC VHF radio is fitted. Enable Buddy track.
See section 18-8
