2. WIRING
2-12
2.6 Transceiver Unit
2.6.1 38P connector 00-8016-038-313761HVF (CN-B102)
How to fabricate 38P connector
How to assemble 38P connector
400
Shield
45
40
Anticorrosive
sheath
Armor
Vinyl Sheath
Core
Insulating tape
Expose cores then wind
shield around armor.
Guide Pin A
Guide Pin B
Guide Pin B
(Small)
Guide Pin A
(Large)
Position No.
