Appendix A Specifications
NI 5911 User Manual A-2 © National Instruments Corporation
Memory record sizes ..............................2,000 samples, to maximum
sample depth determined by
sample frequency
Vertical sensitivity (input ranges)
200 kHz Flexible
Resolution
1 MS 4 MS
100 kHz Flexible
Resolution
1 MS 4 MS
50 kHz Flexible
Resolution
1 MS 4 MS
20 kHz Flexible
Resolution
1 MS 4 MS
10 kHz Flexible
Resolution
1 MS 4 MS
* 1<n<2
32
in oscilloscope mode
Input Range
Noise Referred
to Input
±10 V 174 dBfs/sqrt(Hz)
±5 V 168 dBfs/sqrt(Hz)
±2 V 160 dBfs/sqrt(Hz)
±1 V 154 dBfs/sqrt(Hz)
±0.5 V 148 dBfs/sqrt(Hz)
±0.2 V 140 dBfs/sqrt(Hz)
±0.1 V 134 dBfs/sqrt(Hz)
Sampling
Frequency
Mode
Sample depth
(4 MB option)
Sample depth
(16 MB option)
CBIHWum.book Page 2 Thursday, October 29, 1998 1:56 PM
