Appendix B: The Parameter List
AXIS 700 User’s Manual
64
DefaultRouter = 0.0.0.0 Specifies the Internet address for the default router. All
traffic directed outside the local network (according to
the NetMask) is sent to the default router. Any re-
routing via other routers is done automatically. The
default 0.0.0.0 indicates that no default router is set.
NetMask = 0.0.0.0 Specifies the subnet mask used for determining whether
the traffic should stay within the network or be sent via
a router. For example, the normal class C mask is
255.255.255.0. The default 0.0.0.0 indicates that
automatic router sensing is used.
BOOTPEnable = yes Enables BOOTP for setting the Internet address.
RARPEnable = yes Enables RARP for setting the Internet address.
DHCPEnable = yes Enables DHCP for setting the Internet address.
DomainName = Specifies the name of the domain to which the AXIS 700
belongs. Domain refers to a set of computers on a
network that have been assigned a group name. A
domain might contain two or more workgroups.
PrimaryDNS = 0.0.0.0 Specifies the Internet address of the primary DNS
server. Used e.g. for setting up of destinations with
names instead of Internet addresses.
SecondaryDNS = 0.0.0.0 Specifies the Internet address of the secondary DNS
server, should the primary be unavailable or
disconnected.
NTPServer = Specifies the name or Internet address of the NTP
server used for time synchronization.
[HTTP/FTP]
BaseURL = www.axis.com Points to one of the Axis web sites. Used for external
links, e.g. AXIS 700 support information.
ExternalLink = Specifies the URL to a customized link, e.g. to your
company’s web site. The link will be available from the
AXIS 700 Web browser interface.
ExternalImage = Specifies the URL to the image that will indicate the
customized external link.
[SNMP]
GetCommunityName = public Specifies the community that has read only access to all
supported SNMP objects except WriteCommunity,
SupervisorPassword and ftpPassword. It corresponds to
the ReadCommunity SNMP object.
TrapDestination = 0.0.0.0 Specifies the Internet Address which SNMP traps are
sent to. It corresponds to the TrapAddress SNMP
object. Default is
0.0.0.0
, which means that all SNMP
traps are disabled.
TrapCommunityName = public Specifies the community for all generated SNMP traps. It
corresponds to the TrapCommunity SNMP object.
Parameter name Value Description
