2. WIRING
2-20
2.7 DC-AC Inverter (option)
Use the JIS (Japan Industrial Standard) cable DPYCY-6 or equivalent (max. 5 m) between
the ship’s mains and the DC/AC inverter. For output (100 VAC), use JIS (Japan Industrial
Standards) cable DPYCY-4 or equivalent (max. 50 m).
Conductor
DPYCY-4: S = 4 mm , 2.55 mm
DPYCY-6: S = 6 mm , 3.12 mm
2
Armor
Vinyl sheath
DPYCY-4: 15.9 mm
DPYCY-6: 17.4 mm
2
10 880
Wind vinyl tape.
Fix armor to the clamp.
FV5.5-4
(AC output:Local supply)
FV5.5-6
(DC input: Local supply)
Fabricating JIS cable DPYCY-4, DPYCY-6
