iv
EQUIPMENT LISTS
Standard Supply
Name Type Code No. Qty Remarks
Processor Unit CSH-5210 - 1 set
Control Unit CSH-5211 - 1 set
Transceiver Unit CSH-8030-8L - 1 set
CSH-8040 - 600 stroke
Hull Unit
CSH-8041 -
1 set
400 stroke
CP10-05201 006-910-940 1 set For processor unit Installation
Materials
CP10-05501 006-911-000 1 set For transceiver unit
Installation
Materials
Combinations of the cable are shown below.
Accessories FP10-02701 006-905-030 1 set For control unit
SP10-02901 006-907-700 1 set For processor unit
Spare Parts
SP10-03001 006-910-950 1 set For transceiver unit
Installation materials (Cable combination)
Type Code No.
Transceiver/
Hull units
Processor/
transceiver units
Monitor/processor
units
CP10-05500 000-069-281 S10-6-15
CP10-05510 000-069-282 S10-6-30
CP10-05520 000-069-283
S10-15-5
S10-6-50
CP10-05530 000-069-284 S10-6-15
CP10-05540 000-069-285 S10-6-30
CP10-05550 000-069-286
S10-15-10
S10-6-50
3COX-2P-6C 5 m
CP10-05600 000-069-287 S10-6-15
CP10-05610 000-069-288 S10-6-30
CP10-05620 000-069-289
S10-15-5
S10-6-50
CP10-05630 000-069-290 S10-6-15
CP10-05640 000-069-291 S10-6-30
CP10-05650 000-069-339
S10-15-10
S10-6-50
3COX-2P-6C 10 m
Name Type Code No. Qty Remarks
S10-15-5 006-800-510 5 m
HULL cable
S10-15-10 006-800-520
1
10 m
Between transceiver and hull
units
S10-6-15 006-976-580 15 m
S10-6-30 006-976-590 30 m
Processor
cable
S10-6-50 006-976-600
1
50 m
Between processor and
transceiver units
3COX-2P-6
C 5 m
000-146-500
5 m
Display cable
COX-2P-6
C 10 m
000-146-501
1
10 m
Between display and processor
units
