Page 40 CP500
· O. Zoom: red when the chart is over-zoomed in more than twice normal scale, gray
otherwise.
· Chart Lock: red when the chart is zoomed in more than twice normal scale, gray
otherwise.
NOTE
U. Zoom, O. Zoom and chart lock are used with Flexi zoom selected.
Best Map
Red when a more detailed chart is available under the cursor position.
Data Off
Red when at least one of the following objects or layers is turned off (by the user):
Depths/soundings; Wrecks/obstructions; Tracks/routes; Attention Areas; Nav-Aids.
Declutter
Displays red when clearing overlapping objects.
Dangers
Red when “Guardian Technology” detects one of the following objects: Land, Intertidal,
Depth Area, Rocks, Obstructions, Shoreline Constructions, Fishing Facility, Wrecks,
Dragged area, Diffusion area, Mooring facilities, Pingos and Production installations.
Caution
Red when “Guardian Technology” detects cautionary or restricted area.
6.0.5 Currents Prediction
It is possible to see the variation of the Tidal arrows on the selected area at any given time.
To activate this function follow the procedure:
1. Press [MENU]. Move the ShuttlePoint knob to highlight
SETUP MENU and press [ENT].
2. Move the ShuttlePoint knob to highlight
MAX FUNCTIONS and press [ENT] or move
the ShuttlePoint knob to the right.
3. Move the ShuttlePoint knob to highlight
CURRENTS PREDICTION and press [ENT] or
move the ShuttlePoint knob to the right.
4. A window is shown on the high-left side of the chart.
5. Press [I
NCR. TIME] to increase the time in 30 minute increments.
Press [D
ECR. TIME] to decrease the time in 30 minute increments.
Press [S
ET TIME] to change the date and time manually.
a. Press Alphanumeric key or move the ShuttlePoint knob up or down to select the
number in the date.
b. To select the next number in the Date field, move the ShuttlePoint knob to the right
and repeat step a. until the date is shown.
c. To store the date press [ENT] and the Time will be selected.
d. Press Alphanumeric key or move the ShuttlePoint knob up or down to select the
number in the Time.
e. To select the next number in the Time field, move the ShuttlePoint knob to the right
and repeat step a. until the time is shown.
f. To store the Time, press [ENT] and Speed (SPD) and Direction (DIR) will be
updated in the table.
6. Press [E
XIT].
