CP500 Page 85
18.0 GPS WAAS SMART RECEIVER SPECIFICATIONS
This GPS WAAS Smart Receiver is based on a ultimate GPS engine that delivers accuracy
better than three meters by decoding the GPS correction signals from the satellite-based
WAAS (Wide Area Augmentation System). The GPS engine, interface electronics and the
passive antenna are enclosed inside the water-proof plastic housing. This provides
advanced state of the art GPS performance in an easy to use package.
Physical Characteristics
Color Ivory white
Dimensions 97mm in diameter x 32mm in height (flush mounted) or 61,5mm on flag-pole mount
Weight (without cable) 0,35 lb (160 g)
Cable white 15 meter 8x28AWG cable with 6 pins female connector
Electrical Characteristics
Input Voltage 10 Vdc to 35 Vdc unregulated
Input Current 0.8 Wmax
GPS Receiver Sensitivity -143 dBm (typical)
GPS Performance
Receiver WAAS (North America), EGNOS (Europe), MSAS (Asia)
Geodetic Datum WGS84
Channels 16
Frequency 1575.42MHz (L1, C/A code)
Acquisition Time
Reacquisition < 1 second
Hot Start < 3.5 seconds
Warm Start < 33 seconds
Cold Start < 40 seconds
Accuracy
GPS < 2.5m
DGPS < 2.0m
NMEA Output
Messages GGA, RMC, GSA, GSV, TXT
