CP500 Page 43
7. CREATING MARKS
Definitions:
MARK
Can be a stand alone position or be linked to a Route. A Mark is place on the Chart page using
[MARK] or by entering in information in the
MARK/WAYPONTS List NEW MARK selection.
WAYPOINTS
Always linked to a Route. Are placed on the Chart page using [ROUTE].
NOTE
The difference between a Mark and a Waypoint is
a. When a Route is created using WAYPOINTS and the ROUTE is deleted the WAYPOINTs are
also deleted.
b. If a Route is created using MARKS and the ROUTE is deleted the MARKs remain.
7.0 CREATING A NEW MARK USING THE CHART PAGE
1. Move the ShuttlePoint knob to the desired or approx. Lat/Lon and press [MARK].
2. You will notice a Mark is placed under the location of the Cursor and a popup window
is shown with the exact Lat/Lon of the Mark.
3. If the position is incorrect, pressing [E
DIT] allows changing of the position, Mark name,
icon type and color of the icon.
Figure 7.0 - Mark creation
NOTE
After entering in all the Marks it is a good practice to back up the points to a C-MAP User C-CARD.
Refer to Section 11.
7.1 EDITING A MARK
1. If a Mark has previously been created and you wish to Edit it, using the ShuttlePoint knob
move the cursor over the top of the Mark.
A popup window will be shown:
