1. RADAR OPERATION
1-83
1.44 Alert Box
When error or alarm setting violation is found, the applicable indication appears
(red, flashing) in the Alert Box and the buzzer sounds. The Alert Box is
composed of four lines of information, as shown below.
Silence the buzzer with the [ALARM ACK] key or select the ALARM ACK box
then push the left button. The buzzer and the flashing stop but the alarm
indication remains on the display until the reason for the alarm is removed.
Display Example 1: ERROR and WARNING
Display Example 2: ERROR only
Display Example 3: ERROR and WARNING
Alert Box Configuration
(lines inside box not present in actual box)
- - - - - SYSTEM ERROR - - - - -
VIDEO
- - - - - - WARNING - - - - - -
FORMAT CARD DATA
- - - - AIS ALARM MESSAGE - - - -
AIS: no valid ROT info
rmation
- - - - AIS ALARM MESSAGE - - - -
AIS: no valid ROT info
- - - - - - WARNING - - - - - -
RD CARD DATA
Line 1: Name of ERROR or ALARM category
Line 2: Name of error or alarm
Line 3: Message Category WARNING
Line 4: Name of warning
