3. TARGET TRACKING (TT)
3-5
[TT TARGET MENU]
1 TT SELECT
MANUAL100/
AUTO 25/
AUTO 50/
AUTO 75/
AUTO 100
2 ALL CANCEL
NO/YES
3 REF TARGET VECTOR
OFF/ON
3.5 Automatic Acquisition
The FAR-2xx7 radars can acquire a maximum of 100 targets, the number of
automatically and manually acquired targets determined by the TT TARGET
menu setting.
TT TARGET setting and target acquisition condition
Menu Setting Acquisition condition
MANUAL100 100 targets manually
AUTO25 25 targets automatically, 75 targets manually
AUTO50 50 targets automatically, 50 targets manually
AUTO75 75 targets automatically, 25 targets manually
AUTO100 100 targets automatically
A target just acquired automatically is marked with a broken square and a vector
appears within one minute to indicate the target's motion trend. Within three
minutes, the initial tracking stage is finished and the target becomes ready for
stable tracking. At this point, the broken square mark changes to a solid circle.
(Targets automatically acquired are distinguished from those acquired manually.
The targets which are acquired manually are displayed with a thicker line.)
3.5.1 Enabling auto acquisition
1. Right-click the arrow in the TT ACQ MODE box to show the TT TARGET
menu.
TT TARGET menu
2. Select 1 TT SELECT.
3. Select automatic acquisition condition desired, referring to the table above for
details.
4. Push the right button to close the menu.
Note 1: The TT ACQ MODE box shows AUTO when the automatic acquisition
condition is selected.
Note 2: When the menu-set number of automatically acquired targets is
reached, the message "TARGET-FULL (AUTO)" is displayed at the
right-hand side of screen.
