1. RADAR OPERATION
1-71
Description of function key programs (con’t from previous page)
Item Description
[TT•AIS]
DISP TT Activates/deactivates TT.
DISP AIS Activates/deactivates AIS.
TARGET DATA & ACQ TT: Acquires target; shows data for tracked target selected.
AIS: Activates sleeping AIS target; shows data for AIS target
selected.
PAST POSN INTERVAL Selects past position plotting interval.
REF MARK Inscribes reference mark (for target-based speed).
CPA LIMIT Turns CPA limit on/off.
CPA Enters CPA range.
TCPA Enters TCPA time.
AZ1 Sets Alarm Zone 1.
AZ2 Sets Alarm Zone 2.
TARGET LIST SORT Sorts target list.
TRIAL MANEUVER Executes trial maneuver.
ASSOCATION Changes indication in Association Usage box. See 4.13.
AIS MESSAGE Displays AIS message board.
TRIAL MODE CHANGE Switches between dynamic and static modes.
AIS SCALED SYMBOL Scales AIS target symbols according to target (ship) size.
[OPERATION]
ECHO COLOR Selects echo color.
BACK COLOR Selects background color.
RING Turns range rings on/off.
ALARM1 Sets no. 1 target alarm.
ALARM2 Sets no. 2 target alarm.
WATCH ALARM RESET
Resets watch alarm.
ZOOM Enables zoom.
MARK DELETE Deletes mark (origin mark, waypoint mark, plotter mark).
OWN TRACK DELETE Deletes own ship’s tracks according to setting of OWN TRACK
menu (see page 5-15).
TGT TRACK DELETE Deletes other ship’s tracks according to setting of TARGET TRACK
menu (see page 5-15).
CHART ALIGN Aligns chart with radar picture.
DISPLAY SELECT Selects display mode.
RADAR COMBINE* Dual-radar display. *Non-IMO only
MOB Inscribes MOB mark.
USER DEFAULT Restores user defaults for [F1]-[F3].
For F-KEY
:
1. Set equipment as desired.
2. Long-push (more then 1 s) function key registered as USER
DEFAULT.
3. To recall a setting, do step 2. The radar is then set to stand-by
and "USER DEFAULT" appears at the bottom-right corner.
For STORE:
1. Set equipment as desired.
2. Select STORE at 2 USER DEFAULT BACKUP from page (2/2)
of the OPERATION menu. Select HOLD to register settings.
3. To recall setting, press the function key registered as USER
DEFAULT. The radar is then set to stand-by and "USER
DEFAULT" appears at the bottom-right corner.
TLL Target latitude and longitude output (to chart plotter).
ANCHOR WATCH Enables the anchor watch alarm.
COLOR SHIFT Paint own ship's tracks in different colors.
ICON DISP Hides and shows boxes outside the effective display area.
