1. RADAR OPERATION
1-6
Main menu operation by trackball
1. Use the trackball to select the MENU box at the right side of the screen. The
guidance box at the bottom right corner (see the illustration at the bottom of
the next page for location) now reads "DISP MAIN MENU."
2. Push the left button to display the MAIN menu.
[MAIN MENU]
1 [ECHO]
2 [MARK]
3 [ALARM]
4 [TT
AIS]
5 [PLOTTER]
6 [CARD]
7 [NAV DATA]
8 [NAV LINE
WPT]
9 [CUSTOMIZE
TEST]
Echo processing functions
Mainly turns markers on/off.
Sets guard alarm functions; outputs alarm signal.
Sets TT
and AIS functions.
Chart and track functions
Memory card functions
Turns nav data on/off.
Processes nav lines and waypoints.
Customizes operation; executes diagnostics.
MAIN menu
3. Roll the scrollwheel or trackball to select a menu and push the left button. For
example, select the 2 [MARK] menu.
[MARK]
1 BACK
2 OWN SHIP MARK
OFF/MIN/SCALED
3 STERN MARK
OFF/ON
4 [PI LINE]
5 ANCHOR WATCH
OFF/ON
0.0NM
6 DROP MARK
OFF/ON
7 [INS MARK]
*
1
8 EBL OFFSET BASE
STAB GND/STAB HDG/
STAB NORTH
9 [EBL, VRM, CURSOR SET]*
2
0 RING
OFF/ON
*
1
[BARGE MARK] depending on installation preset.
*
2
IMO and A types show
9 EBL CURSOR BEARING (REL/TRUE)
MARK menu
4. Use the trackball to select a menu item and push the left button.
5. Roll the scrollwheel to select an option and push the left button to validate
your selection.
6. Push the right button consecutively to close the menu. (Several pushes may
be necessary depending on the menu used.)
Note: Hereafter all menu procedures are described using the trackball module
(trackball, scrollwheel, buttons). For sake of brevity we write, "Select [menu item]
(or [menu option])" where you roll the scrollwheel and push the left button (or
scrollwheel) to complete a task on the menu.
