1. RADAR OPERATION
1-68
[CUSTOMIZE•TEST]
1 BACK
2 [DATA BOX]
3 [F1]
4 [F2]
5 [F3]
6 [F4]
7 [OPERATION]
8 [TEST]
[F1]
1 BACK
2 [ECHO]
3 [STD KEY]
4 [TT•AIS]
5 [OPERATION]
6 [PICTURE]
1.36 Function Keys
Less-often used functions are provided in the menu. To avoid opening the
menus to set up the radar for a particular situation, function keys F1-F4 may be
assigned any of the functions shown in the CUSTOMIZE•TEST sub menu.
1.36.1 Activating function keys
To activate the function assigned to a function key, press the key to instantly set
the radar for the preset purpose. Further press the key to select option.
Function key Default setting
F1 Interference Rejector
F2 Echo Stretch
F3 Auto Rain
F4 Heading Line Off
1.36.2 Programming function keys
Do the following to program the function keys.
1. Left-click the MENU box to open the menu.
2. Select 9 [CUSTOMIZE•TEST] then push the scrollwheel.
CUSTOMIZE•TEST menu
3. Select 3 [F1], 4 [F2], 5 [F3] or 6 [F4], whichever function key you want to set,
For example, select 3 [F1] then push the left button.
F1 menu
