1. RADAR OPERATION
1-91
1.45.2 Presetting antenna and display combinations
You can preset the antenna and display combinations for each antenna and
display in the radar system. As an example, the procedure below shows how to
select the no. 1 antenna unit for the no. 2 display unit.
1. Right-click the ANTENNA box to show the ANT SELECT display.
[ANT SELECT]
ANT1: X-BAND
12 FORE
ANT2: X-BAND
12 MAIN TOP
ANT3: X-BAND
MAIN TOP
12
ANT4: X-BAND
AFT
OWN RADAR No.: 2
1 DISP1 ANT1
MASTER
2 DISP2 ANT2
MASTER
* Not available on IMO or
A radar.
9 STORE INTER-SW
NO/YES
0 SUB MONITOR*
OFF/ON
3 DISP3 ANT3
MASTER
4 DISP4 ANT4
MASTER
12
2. Select the display unit for which to select an antenna (at the next step). For
example, select 2 DISP2 to select the no. 2 display unit.
3. The cursor is now selecting the current display and antenna combination for
the no. 2 display unit. Roll the scrollwheel to display ANT1 MASTER and
push the left button.
4. Repeat step 3 and 4 to set other display and antenna combinations.
5. Select 0 STORE INTER-SW.
6. Select YES to save display and antenna combinations.
7. Push the right button twice to close the menu.
Selection considerations
• A antenna unit cannot be controlled from multiple display units. Select one
MASTER display unit for one antenna unit. If two antenna units are set as
masters, the display last-set as master becomes the master and all other
displays are automatically changed to slave.
• An antenna unit without a MASTER display cannot be selected on the sub
display units. If there is no antenna unit set as master, the lowest number
display is automatically set as master.
