1. RADAR OPERATION
1-70
5. Select "2".
6. Select function desired then push the scrollwheel or left button.
7. Push the right button twice to close the menu.
Description of function key programs
Item Description
[ECHO]
PICTURE Selects picture setup function.
IR Selects interference rejection level.
ES Selects echo stretch function.
EAV Selects echo averaging function.
NOISE REJ Turns noise rejector on/off.
ANT SELECT Selects antenna.
PULSE LENGTH Selects pulselength.
A/C SEA SELECT Selects A/C SEA adjustment method.
AUTO RAIN SELECT Selects AUTO RAIN level.
TUNE SELECT Selects tuning adjustment method.
ANT HEIGHT Sets antenna height.
SEA CONDITION Sets sea condition.
2
ND
ECHO REJ Turns 2
nd
trace echo rejector on/off.
PM Turns performance monitor on/off.
SART Turns SART setup conditions on/off.
WIPER Turns wiper (reduce weak and unwanted signals) on/off.
[STD KEY]
ALARM ACK Acknowledges alarm. (Silences audio alarm.)
STBY TX Toggles between stand-by and transmit.
HL OFF Turns heading line on/off.
EBL OFFSET Offsets EBL.
OFF CENTER Off centers the display.
CU TM RESET Returns own ship mark to point 75% of range in use.
PI LINE Turns PI line on/off.
VECTOR TIME Sets vector time.
VECTOR MODE Sets vector mode.
TARGET LIST Displays target list.
TRAIL Sets trail parameters.
BRILL Sets brilliance.
MARK Selects mark to inscribe.
MENU Opens the MAIN menu.
RANGE UP Raises the range scale.
RANGE DOWN Lowers the range scale.
ACQ Acquires target; activates sleeping AIS target.
TARGET DATA Shows target data for selected tracked target or AIS target.
TARGET CANCEL Cancels tracking of tracked target; sleeps AIS target.
