FURUNO
FAR-21x7(-BB)/28x7 SERIES
SP-3 E3519S01P-M
4. Input data sentences ABK, ACK, ALR, BWC, BWR, DBK, DBS, DBT, DPT, DTM, GGA,
GLL, HDT, MTW, MWV, RMB, RMC, RTE, THS, VBW, VDM, VDO,
VDR, VHW, VTG, VWR, VWT, WPL, ZDA
5. Output data sentences ABM, ACK, ALR, BBM, OSD, RSD, TLB, TLL, TTD, TTM, VSD
5. POWER SOURCE
1. Monitor unit MU-201CR 24 VDC:2.3 A or 100-230 VAC: 0.7 A, 1 phase, 50/60 Hz
MU-231CR 24 VDC:3.2 A or 100-230 VAC: 0.9 A, 1 phase, 50/60 Hz
MU-231:1 00-230 VAC; 1.0-0.6 A, 1 phase, 50/60 Hz
MU-190: 100-230 VAC; 0.7-0.4 A, 1 phase, 50/60 Hz
2. Processor unit FAR-2117(-BB)/2817:
24VDC: 7.6A (8.5A), 100-115 VAC: 2.6A (3.0A),
220-230 VAC: 1.6A (1.7A)
FAR-2127(-BB)/2827:
24 VDC: 8.8A (9.7A), 100-115 VAC: 3.0A (3.4A),
220-230 VAC: 1.8A (1.9A)
( ): Value for 42 rpm antenna unit
FAR-2827W:
100-115 VAC: 3.2A, 220-230 VAC: 1.6A
FAR-2137S(-BB)/2837S/2837SW:
100-115 VAC: 3.0A, 220-230 VAC: 1.5A
3. Antenna unit S-band: 200/220/380/440 VAC
, 3ø, 50/60 Hz
Antenna voltage input (100 kt) Model
200 VAC,
ø3, 50 Hz,
220 VAC,
ø3, 60 Hz
380 VAC,
ø3, 50 Hz,
440 VAC,
ø3, 60 Hz
220 VAC,
ø3, 50 Hz
(HSC)
220 VAC,
ø3, 60 Hz
(HSC)
440 VAC,
ø3, 60 Hz
(HSC)
FAR-2137S(-BB) 3.0 A 1.5 A 3.5 A 3.5 A 1.7 A
FAR-2837S 3.0 A 1.5 A - - -
4. Console 115/230 VAC, 1ø, 50/60 Hz
5. Transformer (option) Single phase: RU-1803 (440 VAC, 1 phase, 50/60 Hz)
Triple phase: RU-5693 (100 VAC, 3 phase, 60 Hz)
RU-6522 (220 VAC, 3 phase, 50 Hz)
RU-5466-1 (440 VAC, 3 phase, 50 Hz)
6. ENVIRONMENTAL CONDITIONS
1. Ambient temperature
Display/processor unit/ transceiver/control/power supply unit
-15°C to +55°C
Antenna unit -25°C to +55°C (storage +70°C)
2. Relative humidity less than 95% at 40°C
3. Degree of protection
Display/processor/control/power supply unit: IPX0
Monitor unit 170C Front panel: IP56, Rear panel: IP20
MU-190, MU-231 IP22
Antenna unit: IPX6
4. Vibration IEC 60945 Ed. 4
