3. TARGET TRACKING (TT)
3-14
000
010
020
030
040
050
060
070
080
090
100
110
120
130
140
150
160
170
180
190
200
210
220
230
240
250
260
270
280
290
300
310
320
330
340
350
Target selected for data readout
TT TARGET
No. 01
BRG 25.5°T
RNG 3.4NM
T COG 205.1°T*
T SOG 12.3KN*
CPA 2.9NM
TCPA 12.2MIN
BCR 1.7NM
BCT 20MIN
01
BRG: Bearing from own ship to target
in R (Relative) or T (True)
RNG: Range from own ship to target
COG: Course of target over ground, True or Relative*
SOG: Speed of target over ground*
CPA: Closest Point of Approach of target to own ship
TCPA: Time to CPA
BCR: Bow crossing range of target
BCT: Bow crossing time of target
* CSE and STW are shown
in case of manual speed,
speed through the water.
Tracked target display
You may display the target data for two targets in one data box and the data for
as many as six targets can be displayed. For further details, see section 1.42.
Removing a target data display
Full keyboard: Put the cursor on the data you want to remove then hit the
[TARGET DATA] key.
Cursor menu: TARGET DATA & ACQ
Canceling tracking on a target from target data display
Full keyboard: Put the cursor on the data you want to remove then hit the
[TARGET CANCEL] key.
Cursor menu: TARGET CANCEL
