3. TARGET TRACKING (TT)
3-11
Other TT symbols
Item Symbol Status Remarks
Trial maneuver T
(flashing)
Bottom center
Appears during execution of a trial
maneuver.
Performance
test
S
(flashing)
Bottom center Appears during performance test.
3.8.2 Choosing TT symbol (B, C and W types)
In addition to the "standard" circle TT symbol, you may select from the symbols
shown below, using the full keyboard. This cannot be done with
trackball-type
control unit (RCU-015, RCU-016). However, you can program a function key to do
so, with the combination of the "STD KEY" category and the option "TARGET
DATA."
1. Put the cursor on the TT symbol you want to change.
2. Press the [TARGET DATA] key.
3. Press the [TARGET DATA] key until desired symbol is displayed.
3.8.3 TT symbol brilliance
1. Right-click the BRILL box at the left side of the screen.
2. Select 0 NEXT.
[BRILL1 MENU (2/2)]
1 BACK
2 BRG CURSOR
3 EBL
4 VRM
5 PI LINE
6 TT SYMBOL
7 AIS SYMBOL
8 L/L GRID
9 MARK
0 CHART
BRILL menu, page 2
3. Select 6 TT SYMBOL.
4. Roll the scrollwheel to adjust brilliance.
5. Push the right button twice to close the menu.
