5. VIDEO PLOTTER OPERATION
5-19
[NAV LINE•WPT (1/2)]
1 BACK
2 NAV LINE DATA
OFF/EXT DATA/
INTERNAL DATA/
WPT MARK*
3 NAV LINE SELECT
- -
FORWARD/REVERSE
4 SKIP NEXT WPT
5 NAV LINE WIDTH
9.99NM
6 [WPT SET]
7 [WPT LIST]
8 [NAV LINE SET]
9 [NAV LINE LIST]
0 NEXT
[WPT SET]
1 BACK
2 WPT NO. SELECT
001
3 WPT NAME
4 WPT L/L
_ _°_ _._ _ _ N
_ _ _°_ _. _ _ _E
5 CLEAR DATA
NO/YES
6. With the MARK box selected, roll the scrollwheel to display waypoint number
desired then push the left button. The cursor jumps into the effective display
area and the guidance box reads "MARK / EXIT."
7. Use the trackball to put the cursor where you want to inscribe a waypoint
mark then push the left button to inscribe the mark. The waypoint mark ("
" +
waypoint number) appears at the location selected. (You can see the range
and bearing to the cursor location by monitoring the mark range and bearing
indication just below the MARK box.)
• To enter another waypoint, push the right button when the guidance box reads
"MARK / EXIT" then repeat steps 6-8. ("WPT" should be selected on the
MARK menu.)
• To quit entering waypoints, push the right button when the guidance box reads
"MARK / EXIT."
Entering waypoints by manual input of latitude and longitude
1. Left-click the MENU box to open the menu.
2. Select 8 [NAV LINE•WPT].
* Not available on IMO type
NAV LINE•WPT menu
3. Select 6 [WPT SET].
WPT SET menu
