5. VIDEO PLOTTER OPERATION
5-3
5.4 Radar Map
A radar map is a combination of map lines and symbols whereby the user can
define and input the navigation data, route planning and monitoring data. The
radar map may contain 20,000 points of data. The map data can be saved to
facilitate repeated use on a routine navigation area. The user can create a radar
map on-real time while using the radar for navigation or at leisure time at anchor
or while the radar is not being used. Place of a map can be made for any
waterways apart from the actual own ship location.
The radar map does not affect any radar function.
5.4.1 Showing, hiding the radar map display
From menu
1. Use the trackball to select the MARK box.
2. Push the right button to open the MARK menu.
[MARK MENU]
1 ORIGIN MARK STAB
GND/SEA
2 MARK KIND
ORIGIN MARK(No. )/
ORIGIN MARK(SYM)/
MAP MARK/
WP 1~50/
WP 51~ 100/
WP 101~150/
WP 151~198/
OWN SHIP SHAPE
8 MARK POSN
CURSOR/OS/L/L
00
°000.00 N
000°000.00 E
9 MAP DISPLAY
OFF/ON
0 MAP MARK COLOR*
RED/GRN/BLU/YEL/
CYA/MAG/WHT
* Not available on IMO
or A type
MARK menu
3. Select 9 MAP DISPLAY.
4. Select ON or OFF as applicable.
5. Push the right button to close the menu.
From mark legend
MARK >
MAP
ON
Place cursor on text and
left-click to hide and show
map alternately.
