5. VIDEO PLOTTER OPERATION
5-35
[CARD (1/2)]
1 BACK
2 DRIVE SELECT
A/B/C/D*
3 [READ CARD]
4 [WR MARK]
5 [WR NAV LINE•WPT]
6 [WR OWN TRACK]
7 [WR TARGET TRACK]**
8 [WR SETTING DATA]
9 [WR INSTALL DATA]
0 NEXT
5.13 Replaying Data
Video plotter data (track, marks, etc.) may be replayed on the screen. This is
useful for analyzing past data.
1. Insert memory card into the appropriate slot in an I/F card unit.
2. Left-click the MENU box to open the menu.
3. Select 6 [CARD].
CARD menu
4. Select 2 DRIVE SELECT.
5. Select the drive where you inserted the memory card.
6. Push the left button.
7. Select 3 READ CARD and push the scrollwheel or the left button.
READ CARD menu
8. Select the data to replay.
9. Push the left button to replay selected data.
The message "RD CARD DATA" is shown during playback. If you selected WR
INSTALL DATA, the prompt "POWER ON RESET" appears; turn the power off
and on again to read in installation data.
[READ CARD (1/2)]
1 BACK
2 T200304109
.
.
.
9 W200307318
0 NEXT
* Drives available are shown.
** Not available on IMO type
