5. VIDEO PLOTTER OPERATION
5-24
[NAV LINE SET]
1 BACK
2 NAV LINE NO. SELECT
01
3 NAV LINE NAME
4 NAV LINE ENTRY
— — —
— — —
— — —
— — —
— — —
— — —
— — —
— — —
— — —
— — —
5 CLEAR DATA
NO/YES
5.11 Nav Lines
30 nav lines may be entered, and each line may have up to 30 waypoints.
5.11.1 Entering a new nav line
To enter a nav line, first enter appropriate waypoints. Then, do the following:
1. Left-click the MENU box to open the menu.
2. Select 8 [NAV LINE•WPT].
3. Select 8 [NAV LINE SET].
NAV LINE SET menu
4. Select 2 NAV LINE NO. SELECT.
5. Use the scrollwheel to enter nav line no., in two digits.
6. Select 3 NAV LINE NAME.
7. Use the scrollwheel to enter a name.
8. Select 4 NAV LINE ENTRY.
9. Use the scrollwheel to enter waypoint numbers (in three digits): Select
numeral and push it to set.
10. To enter another nav line, select 0 BACK to return to the NAV LINE SET
menu then repeat steps 4-9.
11. To finish, push the right button several times to close the menu.
