4–30 LM10 MOTOR PROTECTION SYSTEM – INSTRUCTION MANUAL
CONFIGURATION SETTINGS CHAPTER 4: FUNCTIONALITY
4.2.2 Main Menu
The main menu for the configuration settings is shown below. Press the CONFIG key to
access these settings.
DeviceNet fault Off, On Off page 4–34
50 Hz system Off = 60Hz, On = 50Hz Off page 4–34
Poll data 1, 2, 3, 4 1 page 4-34
Reset run hours Resets on selection N/A page 4–34
Administration control Off, On On page 4–34
Auxiliary relay faults
independently selectable
OvrCur, JAM, STALL, UnBalCur,
AuxSense, LoadLoss, PwrFail,
DevNet, Voltage
All Off page 4–36
Restore factory defaults Resets on selection N/A page 4–38
Table 4–1: LM10 Programmable Parameters
Parameter Range/Options Default Reference
GE LM10 1.70
Class: 10
MAC ID: 1
Baud: 500
Configuration
ENGLISH
CTs & CPTs
Starter Type
See page –31.
Configuration
CTs & CPTs
Starter Type
RUN 1 Setup
See page –31.
Configuration
Starter Type
RUN 1 Setup
RUN 2 Setup
See page –32.
Configuration
RUN 1 Setup
RUN 2 Setup
Time Delays
See page –32.
Configuration
RUN 2 Setup
Time Delays
Other Settings
See page –32.
Configuration
Time Delays
Other Settings
Aux Rly Faults
See page –34.
Configuration
Other Settings
Aux Rly Faults
Passcode, Login
See page –34.
Configuration
Aux Rly Faults
Passcode,login
Run Operations
See page –36.
