CHAPTER 5: COMMUNICATIONS DEVICENET OPERATIONS
LM10 MOTOR PROTECTION SYSTEM – INSTRUCTION MANUAL 5–49
Assembly Object, Class Code 4, Instance 5:
Assembly Object, Class Code 4, Instance 52:
Assembly Object, Class Code 4, Instance 53:
Bit 3 Reserved ---
Bit 2 Reserved ---
Bit 1 Run 2 ---
Bit 0 Run 1 ---
Attribute Access Name/Description Data Type Value
3 Set Extended device outputs (see format and
mapping below)
byte see below
Data Formats for Extended Device Outputs
Bit Position Name Value
Bit 7 Reserved ---
Bit 6 Reserved ---
Bit 5 Reserved ---
Bit 4 Reserved ---
Bit 3 Reserved ---
Bit 2 Reset ---
Bit 1 Run 2 ---
Bit 0 Run 1 ---
Attribute Access Name/Description Data type Value
3 Get Device inputs (see format/mapping below) byte see below
Data Formats for Device Inputs
Bit Position Name Value
Bit 7 Reserved ---
Bit 6 Reserved ---
Bit 5 Reserved ---
Bit 4 Reserved ---
Bit 3 Reserved ---
Bit 2 Running 1 ---
Bit 1 Reserved ---
Bit 0 Fault ---
Attribute Access Name/Description Data Type Value
3 Get Device inputs (see format/mapping below) byte see below
Data Formats for Device Inputs
Bit Position Name Value
Bit 7 Reserved ---
Bit 6 Reserved ---
Bit 5 Control from Net ---
Data Formats for Extended Device Outputs
Bit Position Name Value
