Protect PV.630 Operating Instructions
8000047961 BAL 25 of 72
4 System Description
This chapter describes the operating modes and functions of the
equipment.
4.1 Operating Modes
Two different operating modes may be used:
Individual operation
Partner operation
4.1.1 Individual Operation
In individual operation, the inverter works independently and is not
connected to any other inverters. The DC infeed from the PV cells
and the link to the AC mains are only connected to this inverter.
Switching operations, control commands and modifications to set-
ting parameters are only performed by the unit concerned.
4.1.2 Partner Operation
In partner operation, two inverters are connected via a CAN bus.
The DC voltage infeeds of both units can be linked using a cou-
pling breaker. Levels of efficiency can be increased in this operat-
ing mode by running one inverter on two connected PV cells at
less than full power. It is the inverter itself that connects and dis-
connects the DC voltage; it is also responsible for switching the
units on and off.
This operating mode is described in detail in Chapter 5.5.
