15
Connection and Removal of FR-PU07BB
(2) When using an AC adapter
1) Pull out the protective cover toward you to remove
and then insert the output plug of an AC adapter
(sold separately) into the AC adapter connector.
2) Connect the AC adapter (sold separately) to a AC power
supply.
Connector
Protective cover
STF FW
D PU
