Diagnostics and Troubleshooting
Faults codes that will be cleared as soon as their causes disappear
The USF fault can be cleared remotely by means of a logic input (parameter Detected fault reset assignment rSF page 91).
(1) When the CFI is present in the past fault menu, it means the configuration has been interrupted or is not fully finished.
HMI block changed
When an HMI block is replaced by an HMI block configured on a drive with a different rating, the drive locks in Incorrect configuration CFF
fault mode on power-up. If the card has been deliberately changed, the fault can be cleared by returning to factory setting.
Code
Name Possible causes Remedy
CFF Incorrect
configuration
• HMI block replaced by an HMI
block configured on a drive with a
different rating
• The current configuration of
customer parameters is
inconsistent
• Return to factory settings or retrieve the backup
configuration, if it is valid.
• If the fault remains after reverting to the factory settings,
contact your local Schneider Electric representative
CFI
(1)
Invalid configuration • Invalid configuration
The configuration loaded in the
drive via the bus or communication
network is inconsistent. The
configuration upload has been
interrupted or is not fully finished.
• Check the configuration loaded previously.
• Load a compatible configuration
CFI2 Download invalid
configuration
• Interruption of download operation
with Loader or SoMove
• Check connection with Loader or SoMove.
• To reset the default re-start the download operation or
restore the factory setting
USF Undervoltage • Line supply too low
• Transient voltage dip
• Check the voltage and the parameters of Undervoltage
Phase Loss Menu USb- page 95
.
